| Threaded Type | Model | Features | Sensing distance (With TAKEX fiber sensor) |
|||
| F71CR | F80R | F85RN | ||||
| KFT53 | M3x0.5 | 75mm | 130mm | 370mm | ||
| KFT54 | M4x0.7 | 75mm | 130mm | 370mm | ||
| KFT753 | M3x0.5 | 150mm | 260mm | 540mm | ||
| KFT103 | M3x0.5 | 270mm | 460mm | 750mm | ||
| KFT104 | M4x0.7 | 270mm | 460mm | 750mm | ||
| KFT154 | M4x0.7 | 470mm | 600mm | 1150mm | ||
| KFTL103 | M3x0.5 | 270mm | 460mm | 750mm | ||
| KFTL104 | M4x0.7 | 270mm | 460mm | 750mm | ||
| KFTL154 | M4x0.7 | 470mm | 600mm | 1150mm | ||
| 90o Threaded Type | KFTU104 | M4x0.7 | 270mm | 360mm | 450mm | |
| Smooth Type | KFT5C | O.D. Ø1.5 | 75mm | 130mm | 370mm | |
| KFT5CW | O.D. Ø2.9 | 75mm | 130mm | 370mm | ||
| KFT52C | O.D. Ø2 | 75mm | 130mm | 370mm | ||
| KFT10C | O.D. Ø2.9 | 270mm | 460mm | 750mm | ||
| KFT10C30 | O.D. Ø3 | 270mm | 460mm | 750mm | ||
| KFT102C | O.D. Ø2 | 270mm | 460mm | 750mm | ||
| KFT1025C | O.D. Ø2.5 | 270mm | 460mm | 750mm | ||
| KFT254C | O.D. Ø1.5 | 68mm | 90mm | 230mm | ||
| KFTL153C | O.D. Ø3 | 470mm | 600mm | 1150mm | ||
| SUS Tube Type | KFTS253 | M3x0.5 | 25mm | 40mm | 115mm | |
| KFTS254 | M4x0.7 | 25mm | 40mm | 115mm | ||
| KFTS529C | O.D. Ø2.5 | 75mm | 130mm | 370mm | ||
| KFTS53 | M3x0.5 | 75mm | 130mm | 370mm | ||
| KFTS539 | M3x0.5 | 75mm | 130mm | 370mm | ||
| KFTS54 | M4x0.7 | 75mm | 130mm | 370mm | ||
| KFTS104 | M4x0.7 | 270mm | 460mm | 750mm | ||
